General Details for Pipelines Perimeter Security

The FR302 Pipeline Security System provides long-range monitoring (up to 80 km per controller) with precise intrusion location accuracy (± 5 meters). The system is based on fiber-optic Distributed Acoustic Sensing (DAS) combined with AI-based classification, enabling continuous real-time monitoring of oil and gas pipelines across remote and critical environments.

The system protects pipelines by detecting illegal tapping, excavation, and third-party interference before damage or product loss occurs, ensuring early warning and rapid response.

Pipeline Installation

A single-mode fiber-optic sensing cable is installed along the pipeline route, either directly attached to the pipeline or routed nearby within the right-of-way (ROW).

Every vibration and acoustic disturbance is continuously analyzed by the FR302 controller, which generates classified alarms with pinpoint intrusion location.

The system detects:

• Pipeline tampering
• Illegal tapping attempts
• Mechanical impact on pipeline
• Unauthorized excavation near pipeline
• Human activity along pipeline corridor

This enables operators to quickly identify threats and dispatch security or maintenance teams.

Smart Buried Pipeline Monitoring

A fiber-optic sensing cable can be buried along the pipeline at a typical depth of 0.3 m to 1.5 m, creating an invisible and tamper-proof protection layer.

The system detects:

• Human footsteps near pipeline routes
• Manual digging for illegal tapping
• Machine excavation activity
• Tunneling or ground disturbance
• Vehicle and heavy equipment movement

The buried configuration ensures reliable monitoring even in open, remote, or unfenced pipeline sections.

AI-Based Threat Classification

The FR302 does not just detect activity — it intelligently classifies events using advanced AI algorithms, including:

• Human footsteps
• Manual digging
• Machine digging
• Tunneling activity
• Pipeline tampering
• Mechanical impacts
• Vehicle movement
• Heavy machinery operation

This advanced classification delivers high probability of detection with very low nuisance alarms, even in challenging environmental conditions.

Pinpoint Location & Long-Range Coverage

• Location accuracy: Typically within ± 5 meters
• Coverage range: Up to 100 km per system
• Detects multiple simultaneous intrusion events
• Software-defined virtual zones for flexible pipeline monitoring

Precise location information allows rapid response and minimizes product loss or environmental risk.

High Reliability for Pipeline Security

• Cut-immune configuration — system remains operational even if the cable is cut
• 100% intelligent redundant controller design
• No electrical power required in the field
• Immune to EMI, RFI, lightning, and harsh weather conditions
• Designed for 24×7 mission-critical pipeline protection
• Alarms displayed on map with exact meter location and GPS coordinates

Alarm & System Integration

• Alarm outputs via XML, ASCII, Modbus, HTTP, gRPC, and relay contacts
• Seamless integration with Pipeline SCADA and Command & Control systems
• Compatible with GPS/GIS mapping platforms
• Supports centralized monitoring, analytics, and incident management

The FR302 Pipeline Security System provides long-range monitoring (up to 100 km per controller) with precise event location accuracy (± 6 meters). The system is based on fiber-optic Distributed Acoustic Sensing (DAS) combined with advanced AI-based classification, enabling real-time protection of oil, gas, water, and multiproduct pipelines across long and remote routes.

The system secures pipeline corridors by detecting third-party interference, unauthorized activities, and potential threats before damage, leakage, or service disruption occurs.

Smart Pipeline Installation

A single-mode fiber-optic sensing cable is installed along the pipeline route, either directly attached to the pipeline or deployed within the pipeline right-of-way (ROW).

Every vibration and acoustic disturbance along the pipeline is analyzed in real time by the FR-302 controller, generating classified alarms with precise location information.

The system detects:

• Pipeline tampering
• Unauthorized access along pipeline routes
• Mechanical impacts on pipeline
• Excavation near pipeline
• Ground disturbances affecting pipeline integrity

This enables pipeline operators to quickly assess threats and respond before incidents escalate.

Smart Buried Pipeline Monitoring

A fiber-optic sensing cable can be buried along the pipeline corridor at a typical depth of 0.3 m to 1.5 m, providing invisible and tamper-proof protection.

The system detects:

• Human footsteps near pipeline routes
• Manual digging
• Machine excavation
• Tunneling activity
• Vehicle and heavy equipment movement

AI-Based Event Classification

The FR-302 does not only detect disturbances — it intelligently classifies events using advanced artificial intelligence, including:

• Human footsteps
• Manual digging
• Machine digging
• Tunneling activity
• Pipeline tampering
• Vehicle movement
• Heavy machinery operation
• Ground disturbance patterns

This AI-based classification ensures high detection accuracy with very low nuisance alarms, even in harsh outdoor environments.

Pinpoint Location & Long-Range Coverage

• Location accuracy: Typically within ± 5 meters
• Coverage range: Up to 80 km per system
• Detects multiple simultaneous events
• Software-defined virtual zones for flexible pipeline operations

High Reliability for Pipeline Protection

• Cut-immune configuration — system remains operational even if cable is cut
• 100% intelligent redundant controller design
• No electrical power required in the field
• Immune to EMI, RFI, lightning, and environmental conditions
• Designed for 24×7 mission-critical pipeline monitoring
• Alarms displayed on map with precise meter location and GPS coordinates

Alarm & System Integration

• Alarm outputs via XML, ASCII, Modbus, HTTP, gRPC, and relay contacts
• Seamless integration with SCADA and Command & Control systems
• Compatible with GPS/GIS mapping platforms
• Supports centralized monitoring, analytics, and incident management
